Description
The S-480-24 is a compact and reliable AC-DC switching power supply designed to convert universal AC mains input into a stable 24V DC output for marine, industrial and automation applications.
Built with a durable iron housing and protective circuitry, the S-480-24 ensures safe, continuous operation even under demanding marine and industrial conditions — powering PLCs, control panels, LED lighting systems, sensors and automation equipment aboard vessels.
Key Specifications:
– Model: S-480-24
– Type: Regulated Switching Power Supply
– Input Voltage: AC 100–240V, 47–63Hz
– Output Voltage: 24V DC (adjustable)
– Output Current: 20A
– Output Power: 480W
– Housing: Iron housing
– Dimensions: 22.6 cm x 11.5 cm x 5.8 cm
– Weight: Approx. 1.24 kg
– Cooling: Fan-assisted / Free air convection
– Mounting: Panel mount / DIN rail compatible (model dependent)
Key Features:
– Universal AC input — works on 100–240V worldwide
– Stable, regulated 24V DC output
– Built-in short-circuit, overload and overvoltage protection
– Soft-start circuit limits AC surge current
– Compact and lightweight iron housing
– Reliable continuous power delivery
– Suitable for industrial and marine control systems
Applications:
– Marine vessel control panel power supply
– PLC and automation system power
– LED lighting power supply aboard vessels
– CCTV and security system power
– Industrial machinery control power
– Battery charging and DC power distribution systems
V2 Technical LLC is a trusted marine spare parts and electrical equipment supplier based in Ajman, UAE with 20+ years of experience supplying vessels across the Middle East, West Africa and Mexico.
