The Danfoss MBV5000-1101 (Part No. 061B7013) is a marine-grade block test valve designed as part of the Danfoss MBV 5000 block concept — a complete system covering block pressure switches, block pressure transmitters, block test valves and accessories.
Developed specifically to save space, weight and costs while meeting the strict demands of marine equipment and EU stipulations, the MBV 5000 series is the go-to solution for pressure monitoring and isolation aboard vessels worldwide.
Key Specifications:
– Brand: Danfoss
– Part Number: 061B7013
– Model: MBV5000-1101
– Type: Marine Block Test Valve
– Pressure Range: 0 / +180 bar
– Max Working Pressure (MWP): 180 bar
– Temperature Range: -20°C / +120°C
– Pressure Input: 1 x G1/4 (DIN 3852-E)
– Test Pressure Connection: M16 x 2 (Minimess)
– Made In: Poland
Key Features:
– Part of Danfoss MBV 5000 marine block concept
– Shut-off valve for safe exchange of pressure switches without stopping plant
– Minimess test connection for attaching monitoring devices without disrupting operations
– Flange connections on top for simple connection to Danfoss MBC pressure switches or MBS transmitters
– Fast installation — no piping modifications required
– Simple isolation of pressure sensing equipment
– Compact block design saves space and weight
– Fully compliant with EU marine equipment directives
Applications:
– Marine pressure monitoring systems
– Motor, gear and thruster monitoring
– Pump, filter and compressor shut-down systems
– Alarm indication systems aboard vessels
– Offshore and onshore pressure control installations
V2 Technical LLC is a trusted marine spare parts supplier based in Ajman, UAE with 20+ years of experience supplying vessels across the Middle East, West Africa and Mexico.
