Description
The Carrier 06DR241 (Model 06DR241BCC06C0, Part No. 79-66625-00) is a robust semi-hermetic reciprocating compressor from Carrier/Carlyle’s trusted 06D series — widely used in reefer container units, marine refrigeration systems, and commercial chillers.
Designed for reliability in demanding marine cold chain and refrigeration applications, the 06DR241 delivers efficient cooling performance with advanced unloading and lubrication systems that reduce energy consumption and extend service life.
Key Specifications:
– Brand: Carrier / Carlyle
– Model: 06DR241 (06DR241BCC06C0)
– Part Number: 79-66625-00
– Power: 6.5 HP / 7.5 HP (variant dependent)
– Voltage: 380V 50Hz / 460V 60Hz, 3-Phase
– Compatible Refrigerants: R22, R404A, R407C, R134A
– Type: Semi-Hermetic Reciprocating Compressor
– Connection: Brazed Rotolock
– Weight: 260 lb (approx. 118 kg)
– Application: Air conditioner / Chiller / Freezer
Key Features:
– Positive pressure lubrication with built-in oil pressure regulator and automatically reversible oil pump
– Power conserving capacity control valves provide efficient operation at the lowest cost, automatically matching compressor capacity to system load variations
– Suction cutoff unloading reduces energy usage during unloaded operation by shutting off passage from suction manifold
– EER improvement of as much as 39.5% at 33% load
– Reliable semi-hermetic design — serviceable construction
– Suitable for reefer container, marine and industrial refrigeration
Applications:
– Marine vessel refrigeration and cold storage systems
– Reefer container refrigeration units
– Ship air conditioning and chiller systems
– Commercial cold room refrigeration aboard vessels
– Offshore platform cooling systems
– Industrial refrigeration and freezer applications
V2 Technical LLC is a trusted marine spare parts and refrigeration equipment supplier based in Ajman, UAE with 20+ years of experience supplying vessels across the Middle East, West Africa and Mexico.
